Automatic Flexible Denture Injection System — image 1 of 2
Injection System
Automatic Flexible Denture Injection System
Automatic injection system for thermoplastic denture resins, with programmable heating and pneumatic injection stroke.
SKU FD-LZYX-AUTOMade to order · Ships from Tianjin, China
Sales tax is calculated at checkout from your ship-to state. Freight quoted separately.
Prices as published by Fidara Dental Supply. Freight, duties and local charges are not included.
Need volume pricing or a fit-out quote? Request a quote
Volume pricing
- Quantity
- Unit price
- 1–4
- $550.00
- 5+
- $520.00
Specification
- Temperature range
- 100–400 °C, programmable
- Injection
- Pneumatic, 0.6–0.65 MPa
- Heating power
- 450 W
- Cartridge sizes
- Standard flexible-resin cartridges
- Flask clamp
- Rail-mounted, coaxial with injection port
- Supply
- 110 V / 60 Hz
- Dimensions
- 960 × 185 × 400 mm
- Net weight
- 34 kg
Why this unit
An automatic injection system for thermoplastic denture materials. Cartridge temperature and soak time are set on the panel, and the pneumatic stroke fires on a fixed pressure profile rather than by hand feel — which is what makes the second case of the day match the first.
The heating chamber accepts standard cartridge sizes; the flask clamp mounts on the same rail so the injection axis stays aligned without re-shimming between cases. Chamber and clamp are separately removable for cleaning.
Suited to laboratories producing flexible partials, night guards and thermoplastic clasps in routine volume rather than occasionally.
Choosing a flexible denture injection system
- Automation levelAutomatic temperature control, heat-holding, injection and a done alert — the heat-and-inject cycle runs without operator intervention.
- Shop requirementNeeds a compressed-air supply of at least 0.6 MPa.
- Process windowFactory temperature preset is 287 °C; pressure-hold defaults to about 30 s, adjustable 0–50 s. Below 20 s risks incomplete fills and low tooth density.
- TuningAdjust temperature and hold time for altitude and season: product too dark → reduce them; too pale → increase.
