LZYY-II Split Denture Injection System: Separate Heater and Press — image 1 of 5
Split Denture Injection System
LZYY-II Split Denture Injection System: Separate Heater and Press
Split-type flexible denture injection system with a separate temperature-controlled heating unit and a manual screw press frame.
SKU FD-LZYY2-SPLITMade to order · Ships from Tianjin, China
Sales tax is calculated at checkout from your ship-to state. Freight quoted separately.
Prices as published by Fidara Dental Supply. Freight, duties and local charges are not included.
Need volume pricing or a fit-out quote? Request a quote
Volume pricing
- Quantity
- Unit price
- 1–4
- $240.00
- 5–19
- $235.00
- 20+
- $230.00
Specification
- Power supply
- AC 110 V 60 Hz / AC 220 V 50 Hz
- Rated power
- 350 W
- Factory temperature preset
- 287 °C (adjustable)
- Factory holding-time preset
- 660 s (adjustable)
Why this unit
The LZYY-II is the split version of the flexible denture injection system: the heating furnace sits on top of the temperature-control box as a separate benchtop unit, while the press frame is bolted down independently. It injects flexible resin into flasks for removable partial dentures.
The resin cartridge is loaded into the heating cartridge inside the furnace. The controller shows actual temperature and holding time, with factory presets of 287 °C and 660 s, and beeps when the resin is fully melted.
At the beep the operator moves the heated cartridge onto the flask seated in the press frame, inserts the pusher block, and winds the three forcing screws to complete the injection. Because the heater needs no wiring to the press, the split layout is the simplest of the three versions to install: connect the power cord and it is ready.
